| Type | AIR8-710 | ||
| Axes | 6 | ||
| Payload | 8kg | ||
| Manipulator | Reach | 700mm | |
| Positioning accuracy | Position repeatability | ±0.02mm | |
| Ingress Protection | IP67 | ||
| Mounting | Floor/Wall/Ceiling | ||
| Working range | Axis 1 rotation | -170°/+170° | |
| Axis 2 arm | -100°/+135° | ||
| Axis 3 arm | -120°/+156° | ||
| Axis 4 wrist | -200°/+200° | ||
| Axis 5 bend | -135°/+135° | ||
| Axis 6 turn | -360°/+360° | ||
| Rotation rate | Axis 1 rotation | 380°/s | |
| Axis 2 arm | 350°/s | ||
| Axis 3 arm | 480°/s | ||
| Axis 4 wrist | 490°/s | ||
| Axis 5 bend | 565°/s | ||
| Axis 6 turn | 815°/s | ||
| Controllers | inCube20 | ||
Enormous speed advantage.
Only 0.4s standard cycle time with 1kg payload
Lightweight body.
Suitable for operation in intensive working area of enclosed norrow space.
Suitable for high precision production operations in consumer electronics and other industries.
Position repeatability:±0.02mm
Wide application
Widely used in handling, assembly, loading & unloading, grinding, packing, testing and labeling of small workpieces.
